Full Description:
ICONIC MODULAR DYNAMIC
The iconic modular K-Series is the perfect product for you. The unique versatile seat module can be effortlessly modified independently from the frame and is fully adjustable to be able to fit you perfectly. Whether you require a more stable position or are more advanced, the K-Series can be adapted to suit your lifestyle.
ESSENCE OF KÜSCHALL
SEAT MODULE
ERGONOMIC BACKREST BRACE
QUICK AND EASY FOLDING
HYDRO FORMING
Hydroforming is a forming process which allows the shaping of metals into lightweight, structurally stiff and strong pieces. With a high pressure process the tube is fully enclosed in a die prior to pressurization, resulting in new possibilities for complex shapes which are stronger, lighter and more rigid.
CUSTOMIZATION OPTIONS
3 Simple steps and more than 100 design possibilities to make your Küschall wheelchair even more personal:
1. FRAME COLOUR
Select the frame among 5 possibilites - Pure White, Azure Blue, Carmine Red, Space Black, Anthracite Grey
2. DECAL DESIGN
Give a personal touch to your Küschall by adding a decal decoration on the frame. 2 options to choose among: Tag or Bold
3. DECAL COLOUR
Select the decal colour among 8 different possibilites: Red Tag, Black Tag, Red Bold, Black Bold, Dark Grey Bold, Light Grey Bold, Blue Bold, Gold Bold
Specifications
- Seat width: 320 – 500 mm in increments of 20 mm
- Seat depth: 350 – 525 mm in increments of 25 mm
- Knee-to-heel length: 290 – 480 mm in increments of 10 mm
- Backrest height: 270 – 480 mm in increments of 15 mm
- Backrest angle: 74° / 78° / 82° / 86° / 90° / 94°
- Seat height: front: 450 – 520 mm rear: 390 – 490 mm in increments of 10 mm
- Total width: SW + 170 mm
- Frame angle: 75° / 90° V-frame or tapered
- Total length: 75°: approx. 830 - 1055 mm 90°: approx. 760 - 985 mm
- Centre of gravity: 80 mm / 95 mm / 110 mm/ 125 mm / 140 mm
- safe slope: 0º / 3º / 6º
- Total weight unloaded: 7.8 kg
- Transport weight: 5.1 kg
- user weight: 130 kg
*All measurements and weights indicated are based on seat width 400 mm and seat depth 400 mm in the lightest and most compact configuration. Weight and measurements can change with the different configurations.
PRODUCT AVAILABLE INSTORE ONLY
Product Specification:
| Brand | Kushall |
|---|---|
| Brand: | Kushall |
| VAT Exempt: | Yes |
| Warranty (years): | 1 |
| Length (cm): | 83 |
| Width (cm): | 49 |
| Seat Height (cm): | 39 - 52 |
| Seat Depth (cm): | 35 - 52 |
| Seat Width (cm): | 57 |
| Product Weight (kg): | 7.8 |
| Max User Weight (kg): | 130 |
| Product Type: | Active Wheelchairs |
